EXPLORER ULTIMATE

A combination of the best of everything, all the years of experience, history, and heritage that have been created over the years of our work. In order to make this project happen, we had to go back several steps and first redesign the frame for the installation of the ÖHLINS suspension. This change could have been enough for a whole dissertation on how perfect this suspension is, but it wasn’t enough for us. To make things complete we used 27.5″ plus wheels, a Rohloff hub as a gearbox, and Saint brakes with custom-made Galfer 223mm discs to tame this monster. This whole thing is powered by a 750W motor controlled by a handle or by crank in power steering mode.

EXPLORER ULTIMATE: About

SPECS

Frame material: 6082 Aluminum alloy
Front/Rear suspension: CNC machined Front shocks: ÖHLINS TTX AIR 210x55
Rear shocks: ÖHLINS TTX22M 250x70 coil spring shock
Steering system: Handlebar and chest steering system
Drivetrain front: Electric motor 750W with assist mode and throttle

Drivetrain rear: Rohloff Speedhub 500/14 XL FAT
Pedals: Custom designed, ergonomically shaped
Intermediate set of gears: Bearing hub with 22T/28T chainrings

Seat/Footrests: Adjustable carbon-fibre seat and footrests
Chest steering: Adjustable (up,down,angle)
Handlebar: low rise, mid-rise, high rise to choose
Stem: Customized Amoeba Borla
Brakes: Shimano SAINT brakes
Brake discs: Galfer 223mm / Rear 180mm
Wheels: 27,5"+
Tires: 3.0” Continental / Schwalbe / Maxxis
Dimensions with wheels: L=225cm W=98cm H=70cm
Weight: 26 kg / 57 lbs without motor (9.5lbs) & battery (12lbs)
